Our bedding spreaders are engineered to solve the challenges of traditional manual bedding. They ensure a consistent, hygienic environment, which directly correlates to lower somatic cell counts (SCC) and higher milk yield.
Superior Material: Built with Q345B manganese steel for maximum durability and corrosion resistance.
Precision Design: Independent hydraulic controls with options for single or dual-side discharge.
Before heading to the stalls, follow this checklist:
Hydraulic Fluid: Check the sight glass; ensure the fluid level is within the optimal range.
Chain Tension: Inspect the floor chain. It should be firm but not over-tensioned to avoid premature wear.
Debris Removal: Ensure the bin is free of large rocks or metal wires that could jam the conveyor.
Use a loader to fill the bin with bedding materials (sand, sawdust, dry manure solids, or rice husks).
Note: For high-density materials like sand, limit the load to 80% capacity to reduce hydraulic strain.
Height: Lower the discharge arm to 20-30cm above the stall edge.
Speed Matching:
Low chain speed + Medium travel speed for light sawdust coating.
High chain speed + Low travel speed for heavy sand bedding.
Bedding Type | Recommended Settings | Maintenance Focus |
|---|---|---|
Sand | High torque, slow driving | Check the anti-wear layer of the conveyor belt daily |
Sawdust/Rice Husk | High-speed throwing and driving at a constant speed | Prevent materials from drifting on windy days |
Recycled Manure | Adjust at medium speed to keep dry | Pay attention to the discharge port to prevent blockage |
To extend machine life, adhere to this schedule:
Daily: Clean buildup from under the discharge arm.
Weekly: Apply grease to all grease nipples (bearings and pivot pins).
Monthly: Inspect hydraulic filters and replace them if necessary.
Yearly: Full hydraulic oil change (use 46# or 68# anti-wear oil).
fault 1：Conveyor Not Moving
Check: Check if hydraulic couplers are fully seated or if a foreign object is jammed.
fault 2：Uneven Spreading
Check: Check if the material is too wet (clumping) or if the floor chains are out of sync.
Qingdao Jiaojie Machinery is committed to providing the most durable ranching solutions. Our technical team is always ready to assist you with any operational queries.
