Structural composition
Milk storage tank: Generally made of double-layer insulated 304 stainless steel material, with a capacity of 0.5-3 tons, used to store milk or milk powder solution and maintain milk temperature.
Feeding system: equipped with a high-precision quantitative feeding system, which can accurately control the feeding amount each time, and also has an anti drip device to ensure no drip during the feeding process.
Driving system: It often uses 0.5-3-ton electric vehicle dedicated bridges and drive systems, combined with braking and steering systems, for stable driving and low noise. Mining specific tires can be selected to adapt to complex terrain.
Cleaning system: equipped with an automatic cleaning top spray device, which can clean and disinfect components such as milk storage tanks and milk filling pipelines, and also supports manual control.
Control system: Some are equipped with intelligent control systems that can monitor parameters such as battery level, driving speed, and milk addition in real time, and support remote control and data upload.
Mixing system: The milk tank is equipped with a high-speed mixing motor to ensure even mixing of the milk and prevent sedimentation.
Working principle
Milk preparation: Add an appropriate amount of milk or a prepared milk replacer solution to the milk storage tank, which can be mixed evenly through a stirring system. If the temperature of the milk is low, a heating device can be used to raise the temperature.
Transport to feeding point: The operator drives the feeding cart to the calf feeding area, and the vehicle's driving system ensures its flexible and stable movement.
Quantitative feeding: After reaching the designated location, the calf is fed with the set amount of milk through the feeding gun or other feeding device of the feeding system, achieving quantitative and temperature controlled feeding.
Performance characteristics
Improve feeding efficiency: It can quickly transport and feed milk to calves, saving manpower and time. One person can complete the operation, and the double-sided dual steering wheel design further improves efficiency.
Accurate control of milk volume: The high-precision milk feeding system can accurately control the feeding amount of each calf, ensuring nutrient intake and promoting healthy growth of calves.
Ensure hygiene and safety: Food grade materials and automatic cleaning systems prevent bacterial growth, ensuring milk quality and calf dietary safety.
Energy saving and environmental protection: The electric drive system has zero emissions, low noise, energy saving and high efficiency, meets environmental requirements, and reduces the operating costs of the ranch.
Application scenarios
Large scale cattle farm: With a large number of calves, using feeding carts can achieve efficient and precise feeding, improve management level and breeding efficiency, and ensure the uniformity of calf growth and development.
Small scale cattle farms or family ranches: reduce the labor intensity of manual feeding, improve work efficiency, and facilitate scientific and standardized calf feeding management.
Product Specifications
No | Item | DNC-01T |
1 | Power | 4 KW |
2 | Tank Capacity | 1000 liters |
3 | Operating Weight | 1.5 Ton |
4 | Material | Food Grade 304 Stainless Steel |
5 | Material Thickness | Inner 2.5 mm Outer 1.5 mm |
6 | Insulation Thickness | 50 mm Polyurethane overall foam |
7 | Charging Time | 8-10 Hours |
8 | Recharge Mileage | 80 km |
9 | Battery | 60 V 120Ah |
10 | Dimension(cm) | L:380 cm W:130 cm H:185 cm |
Product Configuration
Wagon with 5 kw powerful motor
Double steering wheels
4-point accurate weighing sensors
1.5 kw powerful milk pump; Flow:5 T/h
Milk gun with clear milk flow display
Mixing Blade
Comfortable cabin with double soft seats
3 valves for feeding and cleaning,easy to operate
360 degree rotating cleaning nozzle,No blind spot when cleaning
Well sealed stainless steel lid
Clear Milk Temperature Display
Pasteurize(Optional)
