10000L Milk Cooling Tank for large-farm

Name: 10000L Milk Cooling Tank for large-farm
Brand: Jointtech
Rating: 5.0 (7 reviews)

The 10000L Milk Cooling Tank is designed specifically for large farms, providing efficient and reliable milk cooling to ensure freshness and quality from the moment of collection. Unlike ordinary cooling tanks, this model features rapid cooling technology and a robust stainless steel build, guaranteeing durability even under continuous, heavy-duty use. Its intelligent temperature control system maintains milk at optimal temperatures, preventing spoilage and preserving nutritional value. The spacious 1000L capacity supports large-scale daily production, making it ideal for farms with high milk output. The tank’s easy-to-clean design and automated stirring function streamline operations, saving labor and reducing contamination risks. Whether used in busy dairy barns or modern automated milking parlors, this cooling tank delivers consistent performance and hygienic storage, setting your farm apart by ensuring every batch of milk is fresh and ready for market.

Model:
JJ-10000L
Brand:
Jointtech

Availability:

Quantity:



Inquire Add to Basket

Milk Cooling Tank milk cooler cooling tank milk container milk chiller dairy cooler dairy farm equipment milk cooling chilling milk chilled milk

Product Description

Company Profile

FAQ

Product Description

Dairy farms rely on highly efficient cooling of the milk to keep the milk at a consistent temperature of about 4°C in the milk tanks until the milk is collected for further processing.

Milk is stored at the farms in either closed or open milk tanks. To maintain the quality of the milk it is quickly cooled from 38°C leaving the cow to 4°C in the milk tank. The milk tank is typically equipped with a mixer to accelerate the cooling process and homogenize the milk.

Cooling tank is made of 3 layers of food grade 304 stainless steel. 1st layer: Store Milk 2nd layer: Use Freon R 404(Customized model) to cool down the milk temperature. It cools about 80 degrees of milk in the first layer to 40 degrees. Then the compressor starts to work, and then cools the milk again to stop cooling at 4 degrees. If the milk exceeds 4 degrees, compressor will automatically start cooling until it reach 4 degrees; 3rd layer: The insulation layer of 8 cm thickness

Advantages

With automatic cleaning device and mixing device.
Customized size to fit tank dimensions and ambient temperatures 3.A wide range of controls to secure reliable refrigeration 4.Long service life.

Milk Cooling Tank Specification

Model	Capacity	Material	Power	Voltage	External Size	Packing Size
JJ-500L	500L	SUS304	1.8KW	220V	L:1860mm W:1300mm H:1100mm	L:2250mm W:1400mm H:1200mm
JJ-1000L	1000L	SUS304	3KW	380V	L:2200mm W:1400mm H:1180mm	L:2250mm W:1500mm H:1230mm
JJ-2000L	2000L	SUS304	5KW	380V	L:2760mm W:1860mm H:1180mm	L:2800mm W:1960mm H:1230mm
JJ-3000L	3000L	SUS304	6KW	380V	L:3000mm W:1860mm H:1180mm	L:3050mm W:1960mm H:1300mm
JJ-6000L	6000L	SUS304	14KW	380V	L:3800mm W:2300mm H:2000mm	L:3850mm W:2400mm H:2100mm
JJ-8000L	8000L	SUS304	16KW	380V	L:4000mm W:2350mm H:2000mm	L:4050mm W:2450mm H:1800mm
JJ-10000L	10000L	SUS304	20KW	380V	L:4355mm W:2350mm H:2340mm	L:4360mm W:2450mm H:2400mm

Product Detail

Polishing the tank

(1)The inner tank and all its accessories or parts in contact with milk are made of high-quality 304 stainless steel, which meets the food requirements.

(2)The sealing cover in the tank body is formed by special mold spinning, the arc radius R is 30mm, and the surface is smooth and easy to clean.

Insulation

Made of polyurethane, the thickness is 80mm, when the milk is full, and the milk temperature is 4℃, the outside temperature is not higher than 25℃, to ensure that the temperature rise within 24 hours at normal temperature does not exceed 2℃.

Tank bracket installation

(1) The bottom plate of the refrigeration compressor is made of carbon steel, which is treated with deep anti-corrosion paint.

(2) The milk inlet is set on the milk tank close to the unit side and can be operated without climbing the ladder.

(3) The feet and height of the tank body: the height of the feet can facilitate the cleaning of the ground under the equipment.

Finished Tank

Customized Capacity from 100liters to 20,000liters

3000L

6000L

300/500L

10000L

15000L

Cooling Pipes

Stainless Steel Ladder

Workshop

JOINTTECH02

product-aad16

FAQs

How long is the delivery time? How to ensure the delivery time and quality?

Our products need to be produced after the deposit is paid, and the delivery time is about one month. The products will be tested before shipment and the report will be confirmed to the customer.
Are the operating manuals and safety instructions complete and available in the language we require?

The operating manual and safety guide are comprehensive and contain frequently asked questions when using the device, and can be edited in the language you require.
