The 500L insulation stainless steel electric quantitative milk taxi for calf is a specialized equipment developed by JointTech, designed to meet the needs of calf milk preparation, transportation and feeding. It is suitable for both single-head single-bar feeding and group feeding of calves, and can realize cloud data transmission, bringing intelligent management to pasture operations.
It integrates three functions: modulation, transportation and feeding of calf milk. Whether it is a small pasture with a small number of calves or a large-scale breeding base, it can efficiently complete the feeding work, improving the overall management level of the pasture.
Compared with diesel-powered feeding trucks of the same capacity, this electric milk taxi has lower usage costs. It eliminates the fuel cost of diesel vehicles and reduces maintenance expenses, which greatly saves the daily operation cost of the pasture in the long run.
With a higher milk feeding speed, it can complete the feeding work in a shorter time, saving a lot of working hours. This high efficiency allows breeders to focus on other important tasks, improving the overall work efficiency of the pasture.
The electric operation mode makes the milk taxi run smoothly and quietly, avoiding the stress reaction of calves caused by the noise of diesel vehicles, which is conducive to the healthy growth of calves.
The equipment is equipped with data cloud transmission function, which can record and transmit feeding data in real time. Breeders can monitor the feeding situation remotely, facilitating scientific management and decision-making.
Parameter | Details |
Model | DNC-0.5T |
Brand | JointTech |
Size | 3150*1200*1700mm |
Electric Chassis | 60V120ah lithium battery (battery capacity can be customized) four-wheeled vehicles, running motor 2KW |
Milk Tank Material | Food-grade 304 stainless steel, inner layer 2mm, outer layer 1.5mm |
Insulation Layer | Polyurethane foaming technology, 50mm thick |
Temperature Retention Performance | At 0℃ room temperature, the milk temperature in the tank drops by 0.5℃ per hour |
The chassis adopts a four-wheeled design powered by a 60V120ah lithium battery, which provides strong power for the movement of the milk taxi. The 2KW running motor ensures stable and efficient operation. The battery capacity can be customized according to the actual needs of the pasture, so as to meet the working requirements of different scales of pastures.
Made of food-grade 304 stainless steel, it is safe and hygienic, ensuring the quality of calf milk. The inner layer is 2mm thick and the outer layer is 1.5mm thick, which is strong and durable. The 50mm thick insulation layer using polyurethane foaming technology has excellent thermal insulation performance, which can effectively maintain the temperature of the milk and prevent the milk from cooling too quickly.
There is a 360-degree rotating high-pressure spray cleaning ball inside the milk tank, which can thoroughly clean the residual milk and cleaning liquid in the tank. Driven by the milk pump, the cleaning liquid can clean the pipes, milk cans, milk guns and other parts along the way. The waste liquid can be discharged through the milk gun or sewage outlet, which is convenient and efficient, ensuring the cleanliness and hygiene of the equipment.
The stirring motor at the top of the milk tank provides power for the stirring blade. The blade goes deep into the milk tank through the connecting rod and is only 5cm away from the bottom of the tank. This design can better drive the rotation of the liquid in the tank, which is helpful for the dissolution of milk powder and the cleaning of the tank.
When adding milk, the digital display milk gun can display the flow value (L) in real time. Users can achieve the effect of quantitative milk addition through the flow display, and can also verify it through the weighing display, ensuring accurate feeding.
The weighing display can monitor the existing milk weight in the milk tank in real time, so that breeders can know the remaining milk quantity at any time. The temperature display can ensure that the milk temperature is normal, preventing the calf from diarrhea caused by drinking cold milk, which is of great significance to the health of the calf.
This 500L insulation stainless steel electric quantitative milk taxi for calf has the advantages of advanced technology, excellent performance, convenient operation and low use cost. It can effectively improve the efficiency of calf feeding, reduce the labor intensity of breeders, and ensure the healthy growth of calves. It is an ideal choice for pastures to realize scientific and intelligent management.
Electric chassis of the vehicle
The chassis of the vehicle adopts 60V120ah lithium battery (battery capacity can be customized) four-wheeled vehicles. Running motor 2KW.
Insulation Effect
The milk tank is constructed with a double-layer stainless steel body. The inner liner is 2mm thick, and the outer casing is 1.5mm thick. The insulation layer is made of polyurethane (PU) foam, with a thickness of 50mm. Tests have shown that at room temperature of 0°C, the milk temperature drops by 0.5°C per hour.
How long can it be used after fully charged?
The battery has a range of 80-100 km, which means it can be used for a week in most cases.
How efficient is the calf feeding cart?
