Designed by Qingdao JointTech Machinery, the Milk Taxi DNC02T is a cutting-edge mobile dairy milk server engineered specifically for calf feeding. As a premium calf feeding cart, it combines an electric four-wheel chassis with a high-capacity milk storage tank, enabling seamless transportation of temperature-controlled milk to centralized feeding points. Ideal for both large-scale dairy farms and small family ranches, this equipment simplifies the feeding process while ensuring precision and hygiene.
Branded under Jointtech, the DNC02T model offers a tank capacity of 2000 liters (with options ranging from 500L to 3000L for other variants), making it a versatile solution for diverse farming needs.
The Milk Taxi DNC02T integrates multiple systems to deliver reliable performance, each designed for specific functions:
· Milk Storage Tank: Crafted from double-layer insulated 304 stainless steel (food-grade), it maintains optimal milk temperature. The inner layer (2.5mm thick) and outer layer (1.5mm thick) are separated by 60mm polyurethane foam insulation, ensuring temperature stability for extended periods.
· Precision Feeding System: Equipped with a high-accuracy quantitative feeding mechanism, it controls each feeding volume with minimal error. An anti-drip device further prevents waste during operation.
· Electric Drive System: Powered by a 5 KW motor and paired with a 0.5-3 ton electric vehicle-specific axle, the system ensures smooth, low-noise movement. Optional mining-grade tires enhance adaptability to rough terrain.
· Automatic Cleaning System: Features a top-spray cleaning device for thorough sanitization of the tank and milk pipelines. Manual control is also supported for targeted cleaning.
· Intelligent Control System: Monitors real-time data such as battery level, driving speed, and milk flow. It supports remote operation and data upload, streamlining farm management.
· Mixing System: A high-speed motor stirs milk evenly, preventing sedimentation and ensuring consistent nutrition distribution.
The Milk Taxi DNC02T follows a three-step process to optimize calf feeding:
1. Milk Preparation: Add raw milk or prepared milk replacer to the storage tank. The mixing system blends the liquid uniformly, while optional heating adjusts temperature to calf-friendly levels.
2. Transport to Feeding Zones: Operators drive the cart to calf pens using the stable steering and braking systems, ensuring safe movement across farm terrain.
3. Quantitative Feeding: The precision feeding system dispenses pre-set milk volumes via a feeding gun, guaranteeing each calf receives the right amount of nutrition.
· Efficiency Boost: Single-person operation and a dual-steering wheel design reduce labor costs and save time, ideal for high-volume farms.
· Accurate Nutrition Control: The high-precision feeding system avoids overfeeding or underfeeding, promoting uniform calf growth.
· Hygiene Assurance: Food-grade 304 stainless steel and automatic cleaning prevent bacterial growth, safeguarding calf health.
· Eco-Friendly Operation: Electric-powered with zero emissions, low noise, and lower energy costs compared to diesel alternatives.
· Large-Scale Dairy Farms: Manages high calf counts with consistent feeding, improving herd management efficiency.
· Small Farms & Family Ranches: Reduces manual labor intensity, enabling standardized calf care with minimal effort.
The Milk Taxi DNC02T integrates multiple practical functions to meet diverse farm needs:
· Core functions: Transport, weighing, mixing, insulation, calf feeding, automatic cleaning, and optional pasteurization.
· Key configurations include:
· Dual steering wheels for flexible operation
· 4-point high-precision weighing sensors
· 1.5 KW milk pump (5 T/h flow rate)
· Feeding gun with clear flow display
· 360° rotating cleaning nozzles (no blind spots)
· Sealed stainless steel tank lid
· Real-time milk temperature display
No. | Item | DNC-02T Specification |
1 | Power | 5 KW |
2 | Tank Capacity | 2000 liters |
3 | Operating Weight | 2 Ton |
4 | Material | Food Grade 304 Stainless Steel |
5 | Material Thickness | Inner: 2.5 mm; Outer: 1.5 mm |
6 | Insulation Thickness | 60 mm Polyurethane foam |
7 | Charging Time | 8-10 Hours |
8 | Recharge Mileage | 100 km |
9 | Battery | 72 V, 220Ah |
10 | Dimension | L:450 cm; W:150 cm; H:210 cm |
Product Configuration
Wagon with 5 kw powerful motor
Double steering wheels
4-point accurate weighing sensors
1.5 kw powerful milk pump; Flow:5 T/h
Milk gun with clear milk flow display
Mixing Blade
Comfortable cabin with double soft seats
3 valves for feeding and cleaning,easy to operate
360 degree rotating cleaning nozzle,No blind spot when cleaning
Well sealed stainless steel lid
Clear Milk Temperature Display
Pasteurize(Optional)
