New 36 m³ Triple Vertical Augers Stationary Diesel Engine Steel TMR Mixer for Livestock Feed

New 36 m³ Triple Vertical Augers Stationary Diesel Engine Steel TMR Mixer for Livestock Feed

Name: New 36 m³ Triple Vertical Augers Stationary Diesel Engine Steel TMR Mixer for Livestock Feed
Brand: JOINTTECH
SKU: 184617686
Rating: 5.0 (69 reviews)

The 36 m³ Triple Vertical Augers Stationary Diesel Engine Steel TMR Mixer is engineered for high-volume livestock feed operations, delivering exceptional efficiency and consistency. Featuring three robust vertical mixing augers, it ensures thorough blending of feed ingredients, resulting in uniform nutrition for herds and optimized animal performance. The powerful diesel engine and heavy-duty steel construction guarantee reliable performance in demanding farm environments, minimizing downtime and maintenance costs. Its stationary design is ideal for large-scale feed centers or commercial livestock farms where continuous mixing is essential. Unlike conventional mixers, the triple auger system processes fibrous materials and silage with superior speed, reducing mixing times and improving feed quality. Positioned in a centralized feed area, this mixer allows seamless workflow integration, supporting automated or manual feed distribution. With its advanced mixing technology, durable build, and operational flexibility, the 36 m³ TMR mixer stands out as a premium solution for modern, efficiency-driven livestock businesses.

Model:
STMR-30； STMR-32
Brand:
JOINTTECH
Code:
8436100000

Dimension(mm):	900024502875
speed reducer:	Italian Cornel
Discharge gate motor:	1.5kw
motor:	132 KW
Cutting blade:	21 large blade+ 24 small blade
Max load:	12500kg
Mix Time:	15-20 Minutes
Availability:

Quantity:



Inquire Add to Basket

TMR Mixer animal feeding mixing triple augers mixer big feed mixer stationary mixer fixed feed mixer fodder mixing machine tmr feed mxer fodder mixer feed Mixer

Product Description

Our Advantage

FAQ

Qualification Certificate

Overview of the Product

In the bustling operations of large-scale farms, the Triple Augers Vertical Stationary TMR Mixer stands as a cornerstone equipment, revolutionizing the way feed is prepared and distributed. As a flagship model in the STMR series by Jointtech, this stationary feed mixer is tailor-made for large farms housing beef cattle, dairy cows, goats, horses, and other livestock. Its ingenious design allows mixed feed to be seamlessly discharged into spreaders through optional chain or belt conveyors, streamlining the entire feeding process.

The Triple Auger Vertical Stationary TMR Mixer has a range of outstanding features that make it stand out on the market:

1. Sturdy Mixing Box
The mix box of this mixer is built to last. The side thickness of the mix box is 10mm, and the floor thickness is 20mm. This robust construction can withstand the heavy loads and constant friction during the mixing process, ensuring the mixer's long-term stability and reliability in harsh farming environments.

2. Superior Mixing Performance
The Mix Auger of this mixer is CNC formed, boasting a thickness of 24mm. What's more, an 8mm thick wear-resistant plate is added to it. This special design enables the feed to boil and flip during the mixing process, which not only shortens the mixing time but also ensures that the feed is mixed more evenly. This uniform mixing is crucial for providing balanced nutrition to the livestock, promoting their healthy growth.

3. Durable Cutting Blades
The cutting blades of the Triple Auger Stationary TMR Mixer are 8mm thick and made of tungsten carbide. This high-quality material ensures that the blades are highly resistant to wear and tear, even when dealing with tough and fibrous feed materials. The durability of the cutting blades extends the service life of the mixer, reducing the need for frequent replacements and maintenance.

4. Cost-Effective and Efficient
One of the significant advantages of stationary feed mixers is that they are powered by electricity, which helps save fuel costs compared to fuel-powered alternatives. This is especially beneficial for large farms where energy expenses can be a significant part of the operational budget. Additionally, the simplicity of the mixer's structure leads to minimal maintenance costs, while its efficient design ensures high working efficiency, increasing productivity on the farm.

5. Reliable Weighing System
Equipped with a weighing system from the renowned brand Avery Weigh-Tronix, the Triple Auger Stationary TMR Mixer offers sensitive and stable weighing performance. The clear display allows farmers to accurately measure the amount of feed being mixed, ensuring precise control over the feed formulation and meeting the specific nutritional needs of different livestock.

6. Additional Customization Options
The Triple Auger Stationary TMR Mixer can be equipped with a remote control function and additional wear-resistant plates, according to the specific needs of farmers. These customization options enhance the convenience and durability of the mixer, making it more adaptable to different farming scenarios.

Product Advantages

Italian Komair gearbox
Imported weighing system

、
Chint Electric, durable and long-lasting

、
Cutting blade thickness 8MM, tungsten carbide alloy
Box thickness 10mm, box bottom thickness 20mm
Equipped with variable frequency start and material throwing function

· Advantages: This feed mixer integrates multiple functions, including loading, weighing, cutting, and mixing, which significantly reduces the workload for farm operators.

· Small Volume Options: For those in need of a small volume feed mixer, our factory also manufactures various models with single or double augers, with capacities ranging from 5m³ to 36m³.

· Company Nature: We are a leading livestock farm equipment manufacturer in China, established in 2016.

· Warranty: We provide wearing parts for each machine upon delivery. The warranty period is 1 year, during which we will offer free spare parts if they are damaged. After the warranty, we supply parts at a reasonable price.

· OEM/ODM Orders: Absolutely, we warmly welcome any customized orders.

1. High uniformity of mixing: It can fully mix various additives such as roughage, concentrate, minerals, vitamins, etc., ensuring that every bite of the animal's diet is a stable ratio of concentrate to roughage and a consistent nutrient concentration of the full value diet.

2. Protecting feed nutrition: 25-32 revolutions per minute, minimal damage to feed fiber structure, and able to maintain feed nutrition for a longer period of time.

3. Wide applicability: Fiber based feed such as silage, various bales, straw, etc. can be directly fed into a mixer for shredding and mixing, suitable for both large and medium-sized breeding farms as well as rural scale breeding farms.

4.Save labor costs: The mixing speed is fast, and depending on the volume of the box, each feed mixer can feed 200-2000 cows per day, replacing the work of more than 20 workers, reducing their labor intensity, and improving feeding efficiency.

FAQs

Is the stationary feed mixer easy to operate?

For long-term fixed operation, the mixer should be fixed on the cement base to ensure that the machine is firmly installed. Find a professional electrician to make a reasonable layout of the line to ensure the safety and stability of the machine's power line.
After starting the mixer, use a forklift or conveyor belt to pour the feed raw materials that need to be stirred into the machine. After the raw materials are added, the stirring time for each batch of feed is about 20 minutes.
What are the wiring methods, voltage, and hertz requirements of stationary TMR mixers?

Our standard motor is a 380V 50HZ three-phase AC motor. When wiring, pay attention to the correct phase and avoid reverse connection.The voltage fluctuation should not exceed ±10% and the frequency should be stable at 50HZ to ensure the normal operation of the equipment and extend its service life.If your local voltage and Hertz are different, we can provide customized services.
How does the throwing function of a stationary TMR mixer work?

The normal stirring auger speed of mixer is 25 rpm (50 Hz), when the throwing function is turned on, the auger speed is 45 rpm (80HZ) and maintained for 15-20 seconds. In this way, the feed accumulated on the auger blades can be thrown out under the action of centrifugal force and swept out from the discharge door by the sweeping plate. Ensure that the discharge is clean, there is no debris inside, and it will not become moldy due to high temperature and humidity.
How do I choose a feed mixer that's right for my farm?

Please let us know the distance between the feed area and the cowshed, the number of farm animals, the width of the feeding alley, the size of the site, etc. We will recommend the appropriate model of TMR mixer for you.

We have secured numerous domestic and international certifications—including High-Tech Enterprise status, EU CE certification, ISO 9001, and SGS certification—and were designated a "Gold Supplier" following an on-site inspection by Alibaba. Our equipment is currently utilized across 20 Chinese provinces, serving over 1,000 farms nationwide, and is exported to more than 40 countries and regions across Europe, the Americas, the Middle East, and Southeast Asia. Having successfully obtained over 18 utility model patents, we maintain a steady R&D pace of adding two to three new patents annually to drive our vision of fully intelligent agricultural machinery; we are dedicated to building a premier domestic brand and bringing "Smart Manufacturing from China" to every corner of the globe.
