10m³ Cattle Bedding Spreader

The core function of the cow bed sand-spreading machine is to efficiently and evenly lay sand on cow beds in farms, addressing the issues of low efficiency and high labor intensity associated with manual sand laying, thereby helping to improve animal breeding quality and reduce costs in farming.

Model:
PL-10
Brand:
Jointtech

Availability:

Quantity:



Inquire Add to Basket

Bedding Spreader Sand throwing trucks Sand-spreading vehicle Straw spreader for cow bedding Cattle bedding material spreader Bedding spreader for dairy cows Sand and Soil Spreader Spreader for dry bedding material Cow beddings spreading cart. Dairy cow bedding material

Product Description

Machine Parameter

Customer Use

Introduction

Spreading dry sand in open pen barns can maximize the health of dairy cows and increase milk production. The sand throwing machine is easy to operate, provides uniform thickness in application, and boasts high work efficiency, reducing the labor intensity for workers. It is an ideal tool for spreading dry sand and creating animal bedding.

The machine case is made of Q355B steel material, and the thickness of the auger is 8 mm. It is possible to sprinkle material from both sides of the machine. Low maintenance and no PTO' s, chains or blowers.
The capacity of the bedding spreader is from 5-30 cubic meters, and the volume can be customized. The throwing distance is adjustable from 0.5 to 3 meters, the throwing thickness ranges from 2 to 10 cm, and the working speed is between 3 to 30 km/h.

;

Core Advantages

1 -

Cost reduction and efficiency improvement.

Using automatic machines can save more than 80% of labor costs and reduce bedding waste, lowering farming costs from both labor and material dimensions.
Optimize the resting environment for cows.

Laying sand reduces direct hard contact between hooves and joints with the ground, lowering the risk of limb injuries and hoof diseases.
Suitable for large-scale farming operations.

This equipment is efficient and stable, meeting the needs of various farms and playing an important role in achieving large-scale, modernized farming.

Spreading dry sand in open pen barns can maximize the health of dairy cows and increase milk production. The sand throwing machine is easy to operate, provides uniform thickness in application, and boasts high work efficiency, reducing the labor intensity for workers. It is an ideal tool for spreading dry sand and creating animal bedding.

The machine case is made of Q355 steel material, and the thickness of the auger is 8 mm. It is possible to sprinkle material from both sides of the machine. Low maintenance and no PTO' s, chains or blowers. The capacity of the bedding spreader is from 5-30 cubic meters, and the volume can be customized. The throwing distance is adjustable from 0.5 to 3 meters, the throwing thickness ranges from 2 to 10 cm, and the working speed is between 3 to 30 km/h.

Product Parameters

Model	PL-10
Capacity	10m³
Size	640022502400mm
Engine	Diesel
Power	150 hp
Auger	2 sets
Weight	5000kg
Max Load	14000kg
Discharge Method	Roller type
Driving Speed	3-30km/h
Throwing Thickness	2-10cm
Spreading Width	0.5-3m

Details Images

Discharge structure

(1)The inner door of the discharge door can be adjusted according to the amount of bed cushion material;

(2)The discharge port press plate can be adjusted up and down to control the distance of throwing material.

Ladder

The ladder climbing ladder is facilitate the operator to watch the situation in the box.

Box Body Material: Q355

Floor Steel Thickness: 6 mm

Side Steel Thickness: 3 mm

Hydraulic oil circulation system

Auger

Prevent feed clogging and spread evenly, improve the reliability of equipment and reduce the failure rate. Auger thickness: 8mm.

Engine

Using well-known brand engine, strong power, easy to start in winter, emissions meet the national standards.

Large oil radiator

Double strong tires

The discharge door motor

High speed plunger motor is used in the discharge door, the maximum speed is 1500 RPM; Can provide strong, continuous, stable torque and power to the hammer.
